Radium Engineering

Radium Engineering R35 Nissan GT-R Fuel Hanger Feed Kit - Stainless

  • Sale
  • $693.45
  • Regular price $729.95
  • Will be in stock after

Product SKU: RAD 20-0551-03

The Radium Engineering fuel hanger completely replaces the factory in-tank fuel pump unit in the R35 GT-R and permits up to three 39mm diameter aftermarket pumps (brushed or brushless) to supply fuel to the engine. No permanent vehicle modifications are required for installation. The pumps are housed in an aluminum collector box that is kept full during operation. This ensures that fuel starvation does not occur, even during aggressive driving. The fuel pump outlet port is -10AN ORB female threaded and includes a 6AN male adapter, while the return port is -8AN ORB female threaded and includes a 6AN male adapter. The system is compatible with alternative fuels such as methanol, ethanol, E85, etc. Radium Engineering recommends reviewing the installation instructions (link above) before purchasing.


  • Drop-In OEM Replacement
  • Permits 1, 2, or 3 Pumps
  • Fuel Starvation Protection
  • Integrated 1-Way Fill Valve (x3)
  • High Current Electrical Hardware
  • Compatible with Various Pumps
  • Anodized Aluminum Construction
  • -10AN ORB Threaded Outlet Port
  • -8AN ORB Threaded Return Port
  • -6-Hole Fuel Return Diverter
  • Anodized Aluminum Collector Box
  • Fuel Resistant Tubing and Wiring
  • OEM Hard Line Compatible
  • Stainless Steel Hardware
  • Gasoline, Methanol, and Ethanol Compliant

Package Includes

  • Fuel Filter (-03 Stainless, -05 Microglass)
  • -10AN ORB to 10AN Male Low Profile Fitting
  • -10AN to 6AN Y-Adapter Fittings (x3)
  • Fuel Line Retaining Mounts (x5)
  • R35 Filter Heat Shield Bracket
  • 60mm 2-Piece Filter Clamp
  • -6AN PTFE Fuel Hoses (x4)
  • Stainless Steel Hardware

If installing a Radium in-tank fuel hanger with high-flow aftermarket pumps, the stock R35 fuel lines may not be sufficient. The fuel hanger feed kits include everything required to connect all Radium fuel hangers directly to Radium fuel rails.
